Description:

• Electronics laboratory has been well furnished with Regulated Power Supplies, Function Generators, Cathode Ray Oscilloscopes AND DSOs.
• 18 Work Tables are facilitated in this laboratory
• Each Work Table has proper protecting devices such as fuse and MCB.
• Line Voltage is stabilized by 5 KVA stabilizers.
• The electronics circuits are designed and the results are compared with theoretical values.
• Simulation experiments are executed with PSPICE in ECE Computer Laboratory.
• This laboratory covers all the Electronic Circuits and Devices related laboratory courses prescribed by Anna University.

• All the experimental kits and components are stored in the shelves and racks
• There are 6 double sided work tables present in this laboratory
• This laboratory covers the Microprocessor and Micro controller related laboratory courses and Optical& Microwave laboratory prescribed by Anna University
• Each work table has proper protecting devices such as fuse and MCB.
• Line Voltage is stabilized by 5 KVA stabilizers.
• The lab consists of Scientific Microwave bench , Optical and Microwave Power meters and Two Single mode fiber kits.

Description:

• Signal Processing Laboratory has been well furnished with25 KVA stabilizer and UPS
• There are 75 high configuration systems along with working tables facilitated in this laboratory
• Work tablesarehaving proper protecting devices such as fuse and MCB
• Each system is equipped with executedin ECE Computer Laboratory.
• This laboratory also covers embedded internet connection and IIR work bench for Embedded lab.
• Simulation experiments are system Lab, Computer Networks Lab,VLSI Design Lab, VLSI Laboratory I &VLSI Laboratory II courses prescribed by Anna University.
• Configuration Details: Dell Optiplex 390 DT–Nseries Base Intel core i3 2100 processor, Intel H-61chipset motherboard 2GB DDR-3RAM,320 GB SATA HDD,Dell Keyboard& optical mouse,Dell 18.5” TFT Monitor free DOS Pre loaded.
• Intel Core 2 Duo@2.93 GHz, Intel G41 Chipset Mother Board, 2GB DDR2@800 MHz RAM,320 GB@7200 rpm SATA HDD, Lenovo Keyboard, Lenovo Optical Mouse,Gigabit Ethernet Card, Micro Tower Cabinet, 18.5” TFT Color Monitor
• This lab having Six number of Analog Discovery kits.
• This lab consists of Licensed PSPICE, Xilinx, CADENCE and MATLAB.
• This lab has upgraded as Advanced VLSI laboratory under AICTE MODROBS in the Academic year 18-19.

Description:

• All the experimental kits and components are stored in selves and racks
• There are 9 double sided worktables present in this laboratory.
• This laboratory is covering the Digital, Linear Integrated Circuits,Communication system laboratory courses prescribed by Anna University.
• This lab consists of Communication trainer kits, RF Spectrum Analyser, CRO, AFO, DSO.
• Each work table is having proper protecting devices such as fuse and MCB.

Description:

• This Laboratory contains CRO, DSO for analyzing signals.
• It also contains Soldering facility for the electronic system designs
• This Laboratory was established to encourage the students for doing projects and research works
• All the experimental kits and components are stored in shelvesand racks
• There are 9 double sided work tablespresent in this laboratory.
• This laboratory is covering the Project work and mini Project laboratory courses prescribed by Anna University.
• Each work table is having proper protecting devices such as fuse and MCB.
